Simrad CS66
62 20221859 / F
A dangerous target is illustrated with bold line and with red color.
A dangerous target symbol will flash until acknowledged by the
operator.
The illustration shows a dangerous AIS target.
A lost target is indicated with crossed lines centered on the target
symbol.
The illustration shows a lost AIS target.
A selected target is indicated with broken square around the target
symbol.
The illustration shows a selected AIS target.
If no heading or COG are available the symbol will be oriented toward
the top of the display!
The displaying of AIS and ARPA targets are toggled on/off by
pressing the Overlay Disable toolbar key.
If an optional COP30 is included in the system, targets may be
displayed by pressing the TRGT ON/OFF key.
Target setup
AIS and ARPA targets layout on the display are defined in the
Select Sensors dialog, activated by tapping the Setup menu
followed by the Select Sensors command.
PART OF SELECT SENSORS DIALOG
ARPA radars are identified during installation. If more than one
radar is connected to the system, the ARPA names will be
displayed in the combo box.
