GETTING READY TO USE THE SYSTEM
20221859 / F 39
Used for manually entering speed value.
Echo sounder
The echo sounders are configured during installation of the
CS66 system. Available names will be displayed in the Echo
Sounder drop down field.
Used to enter transducer offset/draft when an echo sounder is
connected. Value to be added to the depth from echo sounder if
the depth values are calculated from the transducer and not
from sea surface.
Wind sensor
The wind sensors are configured during installation of the
CS66 system. Available names will be displayed in the Wind
Sensor drop down field.
ARPA/AIS
Used for defining how ARPA and AIS targets are shown on the
display. Refer Target setup, page 62.
