Sindoh M612 - Laser Optical Unit; Removing Laser Unit

95
Laser Optical Unit
 Please turn the main power off and unplug the power cord before starting any
process. If you do not comply with warning, you may be seriously injured with your
eyes due to the laser beam.
Removing Laser Unit
 Make sure the main power switch is off and the power cord is unplugged before
disassembling or adjusting the laser unit.
11. Open the front door.
12. Remove the rear cover.
13. Remove the left and right side covers.
14. Remove the top cover.
15. Remove the FLAT CABLE of the laser unit and connectors of the harness in the motor
unit section.
