Sindoh M612 - Main Drive Assy Unit Removal

93
 Refer to the harness path to the main board and process the same order when re-
assembling.
Front Door
3. Open the front door [A].
4. Release 3ea of hooks locked at the left and right side to separate the links.
5. Push the left door hinge to the left to separate it from the frame.
6. Push the right door hinge to the left, too to separate it from the frame.
[ A ]
