Sindoh M612 - Fuser Unit; Removing Fuser Unit

105
When dis-assembling, carefully remove the transfer roller without touching the roller.
Fuser Unit
Removing Fuser Unit
 Please turn the main power switch off and wait until the fuser is cooled down before
starting any one of the processes . You may be burnt by the fuser..
 Turn the main switch off.
1. Open the front door.
2. Remove the rear cover.
3. Remove 3 screws[A].
4. Separate 3 connectors which are circled in red.
