60
There are Present sensor detecting the paper when setting the doc. in the tray, and Interval
sentor deciding the timing for the paper feed, and the 1st scan sensor deciding the starting
point of the scan.
Components Layout of A3 ASSY
The A3 ASSY does A3 scan and copying operation with the power delivered using teh
timing belt from gear pulleys among the motor assy. By this time, when feeding A3, install
the clutch and use the power of ADF only in case of operating for A3 related work.
Also, use the bevel gears to change the axis of rotation and then A3 work can be
processed.
