Sindoh M612 - Paper Tray Open;Close Mechanism

25
Components of Drum Cartridge
Cleaning blade Charge cleaner roll Charge roll Wasted toner case Drum
The drum cartridge consist mainly of a drum, a charge roller, a cleaning blade and a wast
toner case as shown in the above image.
Charge cleaner roll
Charge roll
Wasted toner case
