110
not switched.
3) Removing Harness
1. Remove the Main Fan harness which is connected to CN25 in the system card.
2. Remove Sub Fan harness connected to CN49 in the system card.
Separating Pickup roller of the Base Unit (A611/A616DN)
1. Pull out the feed tray.
MAIN FAN
SUB FAN
