116
6. Separate the arm from the shaft by removing cams at both sides, the upper paper guide,
and then E-Ring.
7. You can replace the pick up roller and idle roller by separating them.
Removing Unit Cover of Optional Tray
1. Pull out the cassette tray, and then separate the feed unit from the base unit.
You must turn the power of the machine off before separating the tray unit from the
machine`s base unit.
To Next Page
