4. Separate 4 harnesses from the connectors, and then remove thePDU board from the
base unit.
 Be careful of cutting harness when separating the harnesses from the connectors.
 Be careful of the harness bitten by the hook of the right side cover when re-
assembling.
ADF External Cover
ADF Front Cover
5. Lift up ADF assembly.
6. Release 3 hooks.
7. Open ADF upper cover, and then remove the ADF front cover.
