90
+
When separating the rear side cover from the base unit, be careful of breaking
any of 4ea hooks inside the cover.
Left Cover
3. Remove the rear side door and cover from the base unit.
4. Open the front cover to release the lock of a hook at the bottom side of the machine.
Lift up the cover to separate it from the base unit.
To Next Page
