Service Error Codes(2xx)
Error
Description
Cause and Measure
211
AFE Offset control
error
While correcting AFE offset, the problem occurs, due to
abnormal shadow level, if the input image does not reach the
target even after a certain numbers of correction.
1. Check CIS flat cable and replace it.
2. Replace CIS in case the problem continues.
212
AFE Gain control
error
When correcting AFE Gain, the problem occurs, due to
abnormal shadow level, if the input image does not reach the
target even after a certain numbers of correction.
1. Check the position of reading CIS when doing
calibration.(Check the area diverged from calibration trip)
2. Check CIS flat cable and replace it.
3. Replace CIS in case the problem continues.
213
AFE Register setting
error
When setting Register, the problem occurs, due to
communication errors and incomplete settings.
1. replace the system card.
215
White Strip Read NG
The problem occurs when calibrated white strip images are
under a certain level.
1. Check the position of reading CIS when doing
calibration.(Check the area diverged from calibration trip)
2. Check CIS flat cable and replace it.
3. Replace CIS in case the problem continues.
216
Black Strip Read NG
The problem occurs when calibrated black strip images are
under a certain level.
1. Check the position of reading CIS when doing
calibration.(Check the area diverged from calibration trip)
2. Check CIS flat cable and replace it.
3. Replace CIS in case the problem continues.
217
Front CIS Bad Pixel
error
When reading calibration strip with front side CIS, the problem
occurs if the abnormal images diverged from the shading
correction scope are over a certain number.
1. Check the position of reading CIS when doing
calibration.(Check the area diverged from calibration trip)
2. Check CIS flat cable and replace it.
3. Replace CIS in case the problem continues.
218
Carriage Failed
Leave Home Sensor
The problem occurs when CIS does not pass over the home
sensor installed on the scanner flatbed.
1. Check the harness connected to home sensor.
2. Check the harness connected to scanner motor.
3. Check the gear belt connected to scanner motor,
4. Replace the motor if the problem continues.
219
Carriage Failed
Arrive Home Sensor
The problem occurs when CIS does not arrive at the home
sensor installed on the scanner flatbed.
1. Check the harness connected to home sensor.
2. Check the harness connected to scanner motor.
3. Check the gear belt connected to scanner motor,
4. Replace the motor if the problem continues.
220
Back CIS Bad Pixel
error
When reading calibration strip with back side CIS, the problem
occurs if the number of abnormal image diverged from the
shading correction scope is over a certain number.
1. Check the contamination of the back side calibration strip
