64
5. SYSTEM CARD-FLATBED MOTOR (CN7)
NO.
Signal
Description
1
AOUT1
A -phase of FB Motor
2
AOUT2
/A -phase of FB Motor
3
BOUT1
B -phase of FB Motor
4
BOUT2
/B -phase of FB Motor
6. SYSTEM CARD-LSU (CN11)
NO.
Signal
Description
1
nHSYNC_H
Sync detection signal
2
GND
GND
3
+5SW
LSU_power
4
nSH_H
SAMPLING & HOLD
5
nLDEN_H
Laser Diode enable signal
6
nVIDEO_H
Image data signal
7
GND
GND
7. SYSTEMCARD- POLYGON MOTOR (CN8)
NO.
Signal
Description
1
nLSU_CLK_H
Criterial CLOCK to be supplied to the
polygon motor
2
nREADY_H
Polygon motor`s arrival signal at fixed
speed
3
nSTART_H
Polygon motor`s starting signal
4
GND
GND
5
+24V
+24V power
8. SYSTEMCARD-LSU_2BEAM (CN48)
NO.
Signal
Description
1
COM1
GND
2
nHSYNC_H
Sync detection signal
3
COM1
GND
4
+5SW
LSU_power
