67
9
FAX_IRQ
FAX interrupt signal
10
5VIN
+5V
11
FAX_RESET
FAX reset signal
12
3.3V
+3.3V
13
3.3V
+3.3V
14. SYSTEMCARD-MAIN FAN (CN25)
NO.
Signal
Description
1
MAIN_FAN
FAN operational signal
2
MAIN_FAN_BACK
Detects to reach to the specified RPM
3
COM1
GND
15. SYSTEMCARD- Micro Switch (CN42)
NO.
Signal
Description
1
24VIN
24VIN
2
24V_SW
24V_SW : 24V to become F/B by switch
16. SYSTEMCARD- EXIT SOL (CN26)
NO.
Signal
Description
1
24VIN
24V power
2
EXIT_SOL_L
Paper exit solenoid ON
17. SYSTEMCARD- MPT SOL (CN27)
NO.
Signal
Description
1
24VIN
24V power
2
MPT_SOL_L
MPT solenoid ON
18. SYSTEMCARD- TRAY SOL (CN28)
NO.
Signal
Description
1
24VIN
24V power
2
TRAY_SOL_L
Feed solenoid ON
19. SYSTEMCARD- ADF_MOTOR & Electric Clutch (CN44)
NO.
Signal
Description
1
ADF_AOUT1
A -phase of ADF Motor
