Sintratec S1 - Maintenance; Maintenance intervals; Replacement of a platform

Cleaning and servicing
Sintratec S1 BA_S1_en 1.1 55 / 76
Pos: 183 /Sintratec /Überschrift en/2. Ebene/U - W/Wartung @ 3\ mod_146408 7098128_655 6.docx @ 9340 @ 2 @ 1
8.3 Maintenance
Pos: 184 /Sintratec /Kap./Wartung/ Wartungsinter valle S1 @ 3 \mod_146718003 3042_6556.do cx @ 10008 @ 3 @ 1
8.3.1 Maintenance intervals
Every 150 operating hours
or every 6 months
• Replace fan filters
In case of powder
escaping from the print
container or powder
container
• Replace platform
• Replace rear container wall
Pos: 185 /Sintratec /Kap./Wartung/ Plattform ersetz en S1 @ 3\ mod_14660639 79741_6556.doc x @ 9463 @ 3 @ 1
8.3.2 Replacement of a platform
Note
If powder falls into the collecting tray from the powder container or the print
container, the seal of the respective platform may be worn.
The platform and the seal can be replaced as a single unit.
1. Move the platform to the top end position (using the "Sintratec Central" print
software).
2. Switch off the device and disconnect it from the mains.
Fig.
33
: Replacement of a platform
3. Open the door.
4. Loosen 4 screws (1) and lift the platform (2) off the support.
5. Fit the new platform by applying the same procedure but in reverse.
