Sintratec S1 - Replacing a rear container wall

Cleaning and servicing
56 / 76 Sintratec S1 BA_S1_en 1.1
Pos: 187 /Sintratec /Kap./Wartung/ Schachtrüc kwand ersetzen S 1 @ 3\mod_1 46606584415 7_6556.doc x @ 9468 @ 3 @ 1
8.3.3 Replacing a rear container wall
Note
If powder falls into the rear section from the powder container or the print
container, the seal of the respective rear container wall may be worn.
The rear container wall and the seal can be replaced as a single unit.
1. Move the platform to the bottom end position (using the "Sintratec Central" print
software).
2. Switch off the device and disconnect it from the mains.
Fig.
34
: Removal of cover at rear
3. Loosen 12 screws (1).
4. Remove the cover.
