A33F4IA
4
3
2
1
COUPLING BLOCK RIGHT SIDE VIEW (“R” RIGHT EMBOSSED ON BLOCK)
1. Position 1 (minimum)
2. Position 2 (minimum/intermediate)
3. Position 3 (intermediate/maximum)
4. Position 4 (maximum)
Rear Shoc k Mot ion Ratio D amping Strength
X and XR-S Package Only
Rear shock on the above m entioned models feature 2 adjustments.
Low Speed Com pression Adjuster
The low speed adjuster modifies the damping force for small suspen-
sion veloci ties. This adjuster has 5 turns of adjustment. Use a flat
screwdrive r to adju st it. Turn ing it cloc kwi se i nc reases shock d amp-
ing action (stiffer) for these low compression speeds.
High Speed Compression Adjuster
The high speed adjuster m odif ies the damping force for high suspen-
sion velocities . Use a 17 mm wren ch to adjust it. Turni ng it clock-
wise increases sh ock damp in g actio n (st iffer) for these high com-
pressi on speeds.
