Skyjack SJ6832 RTE Series User Manual

Rough Terrain Electric Scissors
December 2007 Page 49
Section 3 - Operation Start Operation
3.8-1 To Activate Base Control Console
WARNING
Ensure that you maintain three points of
contact when using the ladder to mount/
dismount platform.
1. Use the ladder of aerial platform to access
platform.
2. Close the gate.
3. On platform control console, pull out ” ”
emergency stop button.
4. Use the ladder to dismount from platform.
5. Turn main power disconnect switch to “ ”on
position.
6. On base control console, pull out ” ” emergency
stop button.
7. Insert key into platform/off/base key switch and
select “ ” base position.
3.8-2 To Raise or Lower Platform Using Base
Control Console
WARNING
Be aware of overhead obstructions or
other possible hazards around the aerial
platform when lifting.
WARNING
Do not lower the platform unless the
area below is clear of personnel and
obstructions.
1. Activate base control console (refer to
Section 3.8-1).
2. On base control console, select and hold “ ”
base position on platform/off/base key switch.
Select and hold platform raise/lower switch to either
“ ” raise or “ ” lower position. Release switch
to stop.

Skyjack SJ6832 RTE Series Specifications

General

Working Height	38 ft
Platform Height	32 ft
Lift Capacity	1, 000 lbs
Drive Speed	3.5 mph
Gradeability	30%
Drive Speed (Stowed)	3.5 mph
Maximum Working Height	38 ft
Capacity	1, 000 lbs
Overall Width	68 in
Weight	3, 629 kg
Drive Speed (Elevated)	0.8 km/h
Turning Radius (Outside)	4.27 m
Fuel Tank Capacity	45.4 L
Platform Length	2.44 m
Platform Width	0.76 m
Power Source	Diesel / Electric
Overall Length	130 in
Stowed Height (Rails Up)	2.08 m
Stowed Height (Rails Folded)	1.85 m
Turning Radius (Inside)	5 ft
