Skyjack SJ6832 RTE Series User Manual

Page 54 December 2007
Rough Terrain Electric Scissors
Start Operation Section 3 - Operation
3.8-10 Shutdown Procedure
1. Completely lower the platform.
2. On the platform control console, push in “ ”
emergency stop button.
WARNING
Ensure that you maintain three points of
contact when using the ladder to mount/
dismount platform.
3. Use the ladder to dismount from platform..
4. On base control console, turn platform/off/base
key switch to “ ” off position and remove the key.
5. Turn main power disconnect switch to “ ” off
position.

Skyjack SJ6832 RTE Series Specifications

General

Working Height	38 ft
Platform Height	32 ft
Lift Capacity	1, 000 lbs
Drive Speed	3.5 mph
Gradeability	30%
Drive Speed (Stowed)	3.5 mph
Maximum Working Height	38 ft
Capacity	1, 000 lbs
Overall Width	68 in
Weight	3, 629 kg
Drive Speed (Elevated)	0.8 km/h
Turning Radius (Outside)	4.27 m
Fuel Tank Capacity	45.4 L
Platform Length	2.44 m
Platform Width	0.76 m
Power Source	Diesel / Electric
Overall Length	130 in
Stowed Height (Rails Up)	2.08 m
Stowed Height (Rails Folded)	1.85 m
Turning Radius (Inside)	5 ft
