Skyjack SJ6832 RTE Series User Manual

Page 66 December 2007
Rough Terrain Electric Scissors
Tables Section 4
Table 4.2 Specifications and Features
No Outriggers 3780 kg
With Outriggers 3845 kg
1.77 m
No Outriggers 2.72 m
With Outriggers 3.35 m
1.4 m x 2.4 m
Working 11.6 m
Platform Elevated 9.7 m
Platform Lowered 2.51 m
Drive 9.7 m
Normal Drive 6.1 km/h
Elevated Drive 0.61 km/h
Lift (Rated Load) 39 sec
Lower (Rated Load) 36 sec
Tires
Foam-filled OTR Outrigger - 30.5 x 66 cm
45%
92 dB(A)
106 dB(A)
1115AE_CE
* Weights are approximate; refer to serial nameplate for specific weight.
Model 6832RTE
Weight*
Width
Length
Platform Size
Vibration - acceleration to which operator's body is subjected
does not exceed 0.5 m/sec
2
.
HeightSpeed
Gradeability (Torque Equivalent To)
Guaranteed Sound Power Level (when
equipped with Gasoline Hybrid Power Pack)
Guaranteed Sound Power Level (when
equipped with Diesel Hybrid Power Pack)
Emission sound pressure level at platform does not exceed 76 dB(A).

Skyjack SJ6832 RTE Series Specifications

General

Working Height	38 ft
Platform Height	32 ft
Lift Capacity	1, 000 lbs
Drive Speed	3.5 mph
Gradeability	30%
Drive Speed (Stowed)	3.5 mph
Maximum Working Height	38 ft
Capacity	1, 000 lbs
Overall Width	68 in
Weight	3, 629 kg
Drive Speed (Elevated)	0.8 km/h
Turning Radius (Outside)	4.27 m
Fuel Tank Capacity	45.4 L
Platform Length	2.44 m
Platform Width	0.76 m
Power Source	Diesel / Electric
Overall Length	130 in
Stowed Height (Rails Up)	2.08 m
Stowed Height (Rails Folded)	1.85 m
Turning Radius (Inside)	5 ft
