Skyjack SJ6832 RTE Series User Manual

Rough Terrain Electric Scissors
December 2007 Page 69
Section 4 Tables
Table 4.5 Floor Loading Pressure
Wheel/
Outrigger
Pad
LCP OUP
kg kg kPa
kg/m
2
min* 3780 1675 1340 785
max* 4430 1860 1490 925
min** 3845 1675 1340 650
max** 4495 1860 1490 760
min** 3845 1675 325 650
max** 4495 1860 360 760
1117AC_CE
*
**
NOTE:
MODEL
Gross Aerial
Platform
Weight
Total Aerial Platform Load
6832RTE on
Tires
6832RTE on
Outrigger Pads
min - Total aerial platform weight with no options (no outriggers)
max - Total aerial platform weight + all options (no outriggers) + full capacity
LCP – Locally Concentrated Pressure is a measure of how hard the aerial
platform tire tread presses on the areas in direct contact with the floor. The floor
covering (tile, carpet, etc.) must be able to withstand more than the indicated
values above.
OUP – Overall Uniform Pressure is a measure of the average load the aerial
platform imparts on the whole surface directly underneath it. The structure of the
operating surface (beams, etc.) must be able to withstand more than the indicated
values above.
The LCP or OUP that an individual surface can withstand varies from structure to
structure and is generally determined by the engineer or architect for that particular
structure.
min - Total aerial platform weight with no options + outriggers
max - Total aerial platform weight + all options +outriggers + full capacity

Skyjack SJ6832 RTE Series Specifications

General

Working Height	38 ft
Platform Height	32 ft
Lift Capacity	1, 000 lbs
Drive Speed	3.5 mph
Gradeability	30%
Drive Speed (Stowed)	3.5 mph
Maximum Working Height	38 ft
Capacity	1, 000 lbs
Overall Width	68 in
Weight	3, 629 kg
Drive Speed (Elevated)	0.8 km/h
Turning Radius (Outside)	4.27 m
Fuel Tank Capacity	45.4 L
Platform Length	2.44 m
Platform Width	0.76 m
Power Source	Diesel / Electric
Overall Length	130 in
Stowed Height (Rails Up)	2.08 m
Stowed Height (Rails Folded)	1.85 m
Turning Radius (Inside)	5 ft
