Skyjack SJ6832 RTE Series User Manual

Page 58 December 2007
Rough Terrain Electric Scissors
Loading/Unloading Section 3 - Operation
NOTE
Lift with forks in designated forklift lifting locations as illustrated in Figure 3-19.
Forklift Lifting
Locations (aerial
platforms with no
outriggers)
Forklift Lifting Locations
Figure 3-19. Forklift Lifting Locations
3.10-2 Driving
When driving the aerial platform:
• Ramp or dock capacity should be sufficient to withstand maximum aerial platform weight.
• Ramp should be equipped with side guards to prevent inadvertent fall from the ramp.
• Incline should not exceed aerial platform gradeability (refer to Table 4.2).
• Aerial platform brakes should be checked for proper operation.
• Aerial platform speed should be on high torque setting.
WARNING
When transporting, the aerial platform must be secured to the truck or trailer deck. Tie downs are
available as illustrated in Figure 3-17.

Skyjack SJ6832 RTE Series Specifications

General

Working Height	38 ft
Platform Height	32 ft
Lift Capacity	1, 000 lbs
Drive Speed	3.5 mph
Gradeability	30%
Drive Speed (Stowed)	3.5 mph
Maximum Working Height	38 ft
Capacity	1, 000 lbs
Overall Width	68 in
Weight	3, 629 kg
Drive Speed (Elevated)	0.8 km/h
Turning Radius (Outside)	4.27 m
Fuel Tank Capacity	45.4 L
Platform Length	2.44 m
Platform Width	0.76 m
Power Source	Diesel / Electric
Overall Length	130 in
Stowed Height (Rails Up)	2.08 m
Stowed Height (Rails Folded)	1.85 m
Turning Radius (Inside)	5 ft
