Skyjack SJ6832 RTE Series User Manual

Page 72 December 2007
Rough Terrain Electric Scissors
Tables Section 4
EC Declaration of Conformity
We, SKYJACK INC., declare under our sole responsibility that the product Mobile Elevating Work
Platform
Model number: [*] Serial number: [*]
to which this declaration relates is in conformity with the following directives:
Machinery Directive 2006/42/EC
With guidance from Harmonized European Standard EN280:2013
Notified body: [*]
EC Type Examination Certificate No: [*]
Directive 2014/30/EU
With guidance from Harmonized European Standard EN13309:2010
Testing laboratory: [*]
Directive 2000/14/EC (when equipped with Hybrid Power Pack):
The aerial access platform equipped with diesel engine was a subject to the internal control of
production.
Guaranteed Maximum Sound Power Level – 106dB
The person authorized to compile the Technical Construction File:
[*]
Place of issue:
[*]
Note: In case of unauthorized modification, this Declaration becomes invalid.
Test and Validation: Quality:
[*] For information refer to the English EC Declaration of Conformity provided with your aerial platform.
Table 4.7 EC Declaration of Conformity

Skyjack SJ6832 RTE Series Specifications

General

Working Height	38 ft
Platform Height	32 ft
Lift Capacity	1, 000 lbs
Drive Speed	3.5 mph
Gradeability	30%
Drive Speed (Stowed)	3.5 mph
Maximum Working Height	38 ft
Capacity	1, 000 lbs
Overall Width	68 in
Weight	3, 629 kg
Drive Speed (Elevated)	0.8 km/h
Turning Radius (Outside)	4.27 m
Fuel Tank Capacity	45.4 L
Platform Length	2.44 m
Platform Width	0.76 m
Power Source	Diesel / Electric
Overall Length	130 in
Stowed Height (Rails Up)	2.08 m
Stowed Height (Rails Folded)	1.85 m
Turning Radius (Inside)	5 ft
