Rough Terrain Electric Scissors
December 2007 Page 89
Section 5 Labels
1
No. Label Pictorial Description
1
TM
Platform Control Console
Squeeze “ ” trigger to enable controller.
Operate “ ” rocker switch to steer.
Move controller forward “ ” to raise or backward to lower
platform.
Move controller forward “ ” to drive forward or backward “ ” to
drive reverse.
Select ” on position to start HPP. Select “ ” off position to turn
off HPP.
Select either “ ” drive mode with low speed (high torque) or
” drive mode with high speed (low torque).
Select either “ ” lift mode or “ ” drive mode.
Push “ ” to sound horn.
Push “ ” to disable controls (Emergency Stop).
Light indicates controls enabled.
Read “ ” operating manual.
Platform Control Console
Labels - Model 6832RTE
