SMARTRG INC. PROPRIETARY AND CONFIDENTIAL. ALL RIGHTS RESERVED. COPYRIGHT © 2016 32
2. Select the Layer2 interface to use for the WAN service and click Next. The following page appears.
3. Select the PPP over Ethernet (PPPoE) WAN service type.
4. Modify the other settings as needed, using the information in the following table.
Field Name Description
Enter Service
Description
Enter a name to describe this configuration.
Internet Pro-
tocol Selection
Different scheduling priorities can be applied to statistically multiplexed data flows. Since each
data flow has its own queue, an ill-behaved flow (which has sent larger packets or more packets
per second than the others) will only punish itself and not other sessions. Options are IPv4 Only,
IPv4&IPv6 (Dual Stack), and IPv6 Only.
Note: When you select IPV4&IPV6 or IPV6, the subsequent options presented will change
accordingly.
Enter 802.1P Pri-
ority
Options are 0 - 7. The default is 0.
For tagged service, enter values in this field and the 802.1Q VLAN ID field.
For untagged service, enter -1 (disabled) in this field and the 802.1Q VLAN ID field.
