Field Name Description
Enter 802.1Q
VLAN ID
Options are 0 - 4094. The default is -1 (disabled).
For tagged service, enter values in this field and the 802.1P Priority field.
For untagged service, enter -1 (disabled) in this field and the 802.1P Priority field.
Select VLAN TPID Select the TPID for this VLAN. Options are
0x8100
,
0x88A8
, and
0x9100
.
Internet Pro-
tocol Selection
Select the IP version. Options are
IPv4 Only
,
IPv4&IPv6 (Dual Stack)
, and
IPv6 Only
.
5. Click Next. The following page appears.
