SMART Board GX User Manual

Appendix C Managing the display using RS-232
smarttech.com/kb/171744 94
Commands
Function Set command Get command Response
Power state
k01sA00[Value]<CR>
Where [Value] is one of the
following:
l
0 (standby)
l
1 (on)
k01gi000<CR> Now [Value]<CR>
Where [Value] is one of the
following:
l
ON
l
Standby
Input
k01sB0[Value]<CR>
Where [Value] is one of the
following:
l
00 (ATV)
l
01 (AV)
l
03 (YPBPR)
l
04 (HDMI)
l
06 (VGA)
l
07 (OPS1)
l
09 (Display Port)
l
10 (DTV)
l
0A (Home)
l
0C USB-C
l
14 (HDMI1)
l
24 (HDMI2)
k01gh000<CR> k01rh[Value]<CR>
Where [Value] is one of the
following:
l
X01 (AV input)
l
X03 (YPBPR)
l
X04 (HDMI)
l
X14 (HDMI1)
l
X24 (HDMI2)
l
X07 (OPS1)
l
X09 (Display Port)
l
10A (Home screen)
l
X1C (USB-C)
The “X” in the response can be
either “0” or “1”.
“0” indicates that the video
input does NOT have a video
signal. “1” indicates that the
video input DOES have a
video signal.
Picture size
k01sM004<CR> [N/A] [N/A]
Volume
k01sP[Value]<CR>
Where [Value] is one of the
following:
l
0–100
Note
Volume level is set by
entering a number
between 0 and 100
l
200 (-1 level)
l
201 (+1 level)
k01gf000<CR> k01rf[Value]<CR>
Where Value is a number
between 0 and 100.
Mute
k01sQ[Value]<CR>
Where [Value] is one of the
following:
l
0 (off)
l
1 (on)
k01gg000<CR> k01rg[Value]<CR>
Where [Value] is one of the
following:
l
000 (off)
l
001 (on)

SMART Board GX Specifications

General

Aspect Ratio	16:9
Touch Points	20
Response Time	8 ms
Brightness	350 cd/m²
Display Size	75 inches
Resolution	4K UHD (3840 x 2160)
Connectivity	HDMI, USB, VGA
Display Type	LED
Viewing Angle	178°
Included Software	SMART Notebook
