Mains Screen
Description
Press button
The screen displays battery voltage, charger
voltage, engine speed of lighting tower set and
current time of controller (the number in the
parentheses is week information).
Press button
The screen displays accumulated start times,
accumulated output active energy, accumulated run
time (HH: MM: SS).
Press button
The screen displays currently start time (HH: MM:
SS) and output active energy of this time.
Press button
The screen displays alarms information that
detected by the controller.
Total Data
Starts 1
Hours Run 1:03:40
Energy 14.0kWh
1 2 3 4
Current Boot Data
Hours Run 0:32:45
Energy 7.0kWh
Gens Normal Running
1 2 3 4
Plant Battery 24.0 V
D+ Voltage 24.0 V
Engine Speed 1500 RPM
2017-11-23(4)14:46:00
1 2 3 4
Alarm 01/01
Warn Alarm
High Canopy Temp. Warn
