ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 53 of 83
7.5 FLEXIBLE SENSOR 3 SETTINGS
Table 22 – Flexible Sensor 3 Settings
No.
Parameter
Range
Default
Description
1
Sensor Type
(0~3)
3
0 Not Used
1 Temp. Sensor
2 Pressure Sensor
3 Fuel Level Sensor
2
Curve Type
(0~15)
11
Details of sensor curve
please to see 7.6 SENSOR
CURVE SELECTION.
3
Open Circuit Action
(0~2)
0
0 Warning
1 Shutdown
2 No Action
4
Display Unit
0
0
0: %
5
Sensor High
Shutdown
Enable
(0~1)
0
0 Disabled 1 Enabled
6
Set Value
(0~1000)%
0
7
Delay
(0~3600)s
3
8
Sensor Low
Shutdown
Enable
(0~1)
0
0 Disabled 1 Enabled
9
Set Value
(0~1000)%
0
10
Delay
(0~3600)s
3
11
Sensor High
Warning
Enable
(0~1)
0
0 Disabled 1 Enabled
12
Set Value
(0~1000)%
0
13
Return Value
(0~1000)%
0
14
Delay
(0~3600)s
5
15
Sensor Low
Warning
Enable
(0~1)
1
0 Disabled 1 Enabled
16
Set Value
(0~1000)%
10
17
Return Value
(0~1000)%
15
18
Delay
(0~3600)s
10
19
User-defined
Sensor Curve
1
st
point X
(Resistance)
(0~1000)
0
X-axis and Y-axis of user
defined sensor curve are all
with 8 points,
Unit of X-axis is Ω，
Units of X-axis are as
follows:
Pressure：kPa
Fuel Level：%
Temp.：℃
20
2
nd
point X
(Resistance)
(0~1000)
20
21
3
rd
point X
(Resistance)
(0~1000)
40
22
4
th
point X
(Resistance)
(0~1000)
80
23
5
th
point X
(Resistance)
(0~1000)
100
24
6
th
point X
(Resistance)
(0~1000)
120
25
7
th
point X
(Resistance)
(0~1000)
160
