ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 19 of 83
No.
Operation Process
Panel Display
3
If engine speed, generator voltage and frequency has
reached on-load requirements (speed ≥ on-load speed,
voltage ≥ on-load voltage and frequency ≥ on-load
frequency), all the lights will illuminate in proper order and the
illumination interval delay is 2s (can be set as 1s~300s).
4
When ―Current Time‖ is 07:06:00 (controller’s current time
can be set via PC software) manually select 02 Mode Close(if
select, light tower set will not start according to the sunset
time unless to reselect 01 Mode Start), then 1#～4# lights
will off in proper order and the extinguishing interval delay can
be set as 1s～300s. The light tower set begin stopping when
all the lights off.
Remark: The Sunrise/Sunset mode will be canceled automatically when select other auto start mode！
4.6 AUTO REMOTE START/STOP OPERATION
4.6.1 AUTO REMOTE START MODE SETTING
Table 10 – Auto Remote Start Mode Setting
No.
Process
Description
Panel Display
1
Config input
port
Configure input port 1 as Remote Start Input.
/
2
Enter into
Auto Timer
Mode
detailed
setting
navigation
screen
Press ，its indicator lights on, and lighting tower
set enters into Auto Start Mode. Meanwhile, the
panel display Timer Mode Select screen; Press
and to select 01 Remote Start Mode.
Timer Mode Select
01 Remote Start Mode
02 Auto Timer Mode
03 Sunrise/set Mode
Stop Time 07:06:00
Start Time 16:55:00
Current Time 15:56:00
Gens Normal Running
1 2 3 4
Stop Time 07:06:00
Start Time 16:55:00
Current Time 16:55:54
2# Light On 2s
1 2 3 4
Stop Time 07:06:00
Start Time 16:55:00
Current Time 07:06:00
4# Light Off 2s
1 2 3 4
Auto Sunrise/set Mode
Start Time 16:55:00
Current Time 07:06:09
Stop Cooling Delay 59s
1 2 3 4
