ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 73 of 83
10.3 CUMMINS QSM11 (IMPORT)
It is suitable for CM570 engine control module. Engine type is QSM11 G1, QSM11 G2.
Table 36 - C1Pin Connector
Terminals of controller
C1 connector
Remark
Aux. output 1
5&8
Aux. output 1 configured as ―Fuel Output‖.
Outside expand relay, when fuel output,
making port 5 and port 8 of C1 be connected.
Start relay output
-
Connect to starter coil directly.
Table 37 - 3Pins Data Link Connector
Terminals of controller
3 pins data link connector
Remark
C
CAN communication shielding line (connect
with ECU terminal only).
CAN(H)
A
CAN(L)
B
Engine type: Cummins ISB
10.4 CUMMINS QSX15-CM570
It is suitable for CM570 engine control module. Engine type is QSX15.
Table 38 - 50Pins Connector
Terminals of controller
50 pins connector
Remark
Aux. output 1
38
Oil spout switch; Aux. output 1 configured as
―Fuel Output‖.
Starter relay output
-
Connect to starter coil directly.
Table 39 - 9Pins Connector
Terminals of controller
9 pins connector
Remark
SAE J1939 shield-E
CAN communication shielding line
(Connect with ECU terminal only).
CAN(H)
SAE J1939 signal-C
CAN(L)
SAE J1939 return-D
Engine type: Cummins QSX15-CM570
10.5 CUMMINS QSM11
Table 40 - Engine OEM Connector
Terminals of controller
OEM connector of engine
Remark
Aux. output 1
38
Aux. output 1 configured as ―Fuel Output‖.
Starter relay output
-
Connect with starter coil directly.
-
CAN communication shielding line.
CAN(H)
46
CAN(L)
37
