ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 72 of 83
10 CONNECTIONS OF CONTROLLER WITH J1939 ENGINE
10.1 CUMMINS ISB/ISBE
Table 32 - Connector B
Terminals of controller
Connector B
Remark
Aux. output 1
39
Aux. output 1 configured as ―Fuel
Output‖
Start relay output
-
Connect with starter coil directly.
Auxiliary output 2
Expand 30A relay, battery
voltage of 01,07,12,13 is
supplied by relay.
ECU power
Set Auxiliary output 2 as ―ECU power‖.
Table 33 - 9Pins Connector
Terminals of controller
9 pins connector
Remark
SAE J1939 shield
CAN communication shielding line
(connect with ECU terminal only).
CAN(H)
SAE J1939 signal
CAN(L)
SAE J1939 return
Engine type: Cummins ISB
10.2 CUMMINS QSL9
Suitable for CM850 engine control mode
Table 34 - 50Pins Connector
Terminals of controller
50 pins connector
Remark
Aux. output 1
39
Aux. output 1 configured as ―Fuel
Output‖
Starter relay output
-
Connect to 34 starter coil directly.
Table 35 - 9Pins Connector
Terminals of controller
9 pins connector
Remark
SAE J1939 shield-E
CAN communication shielding line
(connect with ECU terminal only).
CAN(H)
SAE J1939 signal-C
CAN(L)
SAE J1939 return-D
Engine type: Cummins-CM850
