ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 20 of 83
No.
Process
Description
Panel Display
3
Confirm
remote start
mode
Press to confirm remote start mode, and
then controller will jump to the 2
nd
page. Meanwhile,
remote start mode set completely.
4.6.2 AUTO REMOTE START/STOP PROCESS OPERATION
Table 11 – Remote Start/Stop Operation
No.
Operation Process
Panel Display
1
Configure controller as Remote Start Mode.
2
When remote start input port is active, remote start delay
begins and audible alarm relay is active (if configured). When
remote start delay is over and remote start signal is active,
light tower set begins cranking.
3
If engine speed, generator voltage and frequency has
reached on-load requirements (speed ≥ on-load speed,
voltage ≥ on-load voltage and frequency ≥ on-load
frequency), all the lights will illuminate in proper order and the
illumination interval delay is 2s (can be set as 1s~300s).
4
When remote start input port is inactive, remote stop delay
begins; when stop delay is over, 1#～4# lights will off in
proper order and the extinguishing interval delay can be set
as 1s～300s. The light tower set begin stopping when all the
lights off.
Remote Start Mode
Remote Start
Current Time 17:30:06
Fuel Output 1s
1 2 3 4
Remote Start Mode
Start Delay 5s
Current Time 17:30:01
Standby
1 2 3 4
Remote Start Mode
Stop Delay 5s
Current Time 07:00:00
Gens Normal Running
1 2 3 4
Remote Start Mode
Remote Start
Current Time 17:30:58
1# Light On 2s
1 2 3 4
Remote Start Mode
Wait Remote Start
Current Time 17:30:00
Standby
1 2 3 4
Remote Start Mode
Wait Remote Start
Current Time 17:30:00
Standby
1 2 3 4
