ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 60 of 83
No.
Type
Description
56
Reserved
57
Reserved
58
Reserved
59
Mains Supply Active
When the input port is active, controller's power harvesting port
detects mains voltage, and controller controls lighting tower follows
the logic of mains supply.
NOTE: The user-defined names of input port 1~5 can be set only via PC software.
7.10 DEFINITION OF PROGRAMMABLE INPUT PORT 1-5
Table 28 – Definition of Input Ports
No.
Type
Range
Default
Function Description
1
User-defined
Active
Type
0~1
0
0 Close to Activate
1 Open to Activate
2
Working
Range
0~3
2
0 Never: input port is
deactivated.
1 Always: input always been
detected.
2 From Crank: detection of input
port starts from crank.
3 From Safety On: detection of
input port starts from safety on
delay expired. .
3
Action
0~3
1
0 Indication: only display status
without warning and shutdown.
1 Warning: only warning without
shutdown.
2 Shutdown: alarm and
shutdown.
3 Trip and Stop: alarm→
generator ramp-off load→stop
after cooling.
4
Delay
(0~20.0)s
2.0
5
User-defined Name
Users can define
input port name
Chinese: 输入口
1~5;
English: Input 1~5
PC software can write 10
Chinese characters and 20
English characters.
