ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 54 of 83
No.
Parameter
Range
Default
Description
26
8
th
point X
(Resistance)
(0~1000)
200
27
1
st
point Y(Value)
(0~4000)
0
28
2
nd
point Y(Value)
(0~4000)
10
29
3
rd
point Y(Value)
(0~4000)
20
30
4
th
point Y(Value)
(0~4000)
40
31
5
th
point Y(Value)
(0~4000)
50
32
6
th
point Y(Value)
(0~4000)
60
33
7
th
point Y(Value)
(0~4000)
80
34
8
th
point Y(Value)
(0~4000)
100
35
User-defined Strings
User-defined
sensor
name
Chinese：燃油液
位
English：Fuel
Level
PC software can write 10
Chinese characters and 20
English characters.
7.6 SENSOR CURVE SELECTION
Table 23 – Sensor Curves
No.
Items
Content
Remark
1
Temperature
Sensor
0 Not Used
1 Digital closed for high temperature
2 Digital open for high temperature
3 User defined
4 VDO 120 degrees C
5 Datcon high
6 Datcon low
7 SGX 120 degrees C
8 Cummins
9 SGH 120 degrees C
10 Curtis
11 SGD 120 degrees C
12 Pt100
13 Reserved
14 Reserved
15 Reserved
The range of user-defined
resistor type sensor is
(0-999.9) Ω; factory default is
11 SGD 120 degrees C curve.
User defined sensor curve can
be set via PC software.
2
Oil pressure
Sensor
0 Not Used
1 Digital closed for low pressure
2 Digital open for low pressure
3 User defined
4 VDO 5 bar
5 VDO 10 bar
6 Datcon 5 bar
7 Datcon 10 bar
8 Datcon 7 bar
The range of user-defined
resistor type sensor is
(0-999.9) Ω; factory default is
13 SGD 10 bar sensor curve.
User defined sensor curve can
be set via utility software.
