ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 74 of 83
Engine type: common J1939
10.6 CUMMINS QSZ13
Table 41 - Engine OEM Connector
Terminals of controller
OEM connector of engine
Remark
Aux. output 1
45
Aux. output 1 configured as ―Fuel Output‖
Starter relay output
-
Connect to starter coil directly
Aux. output 2
16&41
Setting to idle speed control, normally open
output. Making 16 connect to 41 during
high-speed running of controller via external
expansion relay.
Aux. output 3
19&41
Setting to pulse raise speed control,
normally open output. Making 19 connect
with 41 for 0.1s during high-speed warming
of controller via external expansion relay.
CAN GND
-
CAN communication shielding line.
CAN(H)
1
CAN(L)
21
Engine type: Common J1939
10.7 DETROIT DIESEL DDEC III / IV
Table 42 - Engine CAN Connector
Terminals of controller
CAN port of engine
Remark
Aux. output 1
Expand 30A relay, battery
voltage of ECU is supplied by
relay.
Aux. output 1 configured as ―Fuel Output‖.
Start relay output
-
Connect to starter coil directly.
-
CAN communication shielding line.
CAN(H)
CAN(H)
CAN(L)
CAN(L)
Engine type: Common J1939
10.8 DEUTZ EMR2
Table 43 - F Connector
Terminals of controller
F connector
Remark
Aux. output 1
Expand 30A relay, battery
voltage of 14 is supplied
by relay. Fuse is 16A.
Aux. output 1 configured as ―Fuel Output‖.
Starter relay output
-
Connect to starter coil directly.
-
1
Connect to battery negative pole.
-
CAN communication shielding line.
CAN(H)
12
