ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 77 of 83
10.15 VOLVO EDC3
Suitable engine control mode is TAD1240, TAD1241, and TAD1242.
Table 52 - ―Stand alone‖ Connector
Terminals of controller
―Stand alone‖ connector
Remark
Aux. output 1
H
Aux. output 1 configured as ―Fuel Output‖.
Start relay output
E
Auxiliary Output 2
P
ECU power
Configurable output 2,"ECU power" .
Table 52 - ―Data bus‖ Connector
Terminals of controller
―Data bus‖ connector
Remark
-
CAN communication shielding line.
CAN(H)
1
CAN(L)
2
Engine type: Volvo
NOTE: When this engine type is selected, preheating time should be set to at least 3 seconds.
10.16 VOLVO EDC4
Suitable engine types: TD520, TAD520 (optional), TD720, TAD720 (optional), TAD721, TAD722, and
TAD732.
Table 54 - Connector
Terminals of controller
Connector
Remark
Aux. output 1
Expanded 30A relay, and
relay offers battery voltage for
terminal14. Fuse is 16A
Aux. output 1 configured as ―Fuel Output‖.
Start relay output
-
Connect to starter coil directly.
1
Connected to negative of battery.
-
CAN communication shielding line.
CAN(H)
12
CAN(L)
13
Engine type: VolvoEDC4
10.17 VOLVO-EMS2
Volvo Engine types are TAD734, TAD940, TAD941, TAD1640, TAD1641, and TAD1642.
Table 55 - Engine CAN Connector
Terminals of controller
Engine’s CAN port
Remark
Auxiliary output 1
6
ECU stop
Configurable output 1 ―ECU stop‖.
Auxiliary output 2
5
ECU power
Configurable output 2 ―ECU power‖.
3
Negative power
4
Positive power
