ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 65 of 83
No.
Type
Description
98
Sensor 2 Low Shutdown
Active when the generator is shutdown due to sensor 2 is too
low.
99
Sensor 3 Open Circuit Warning
Active when the generator is warning due to sensor 3 is open
circuit
100
Sensor 3 High Warning
Active when the generator is warning due to sensor 3 is too
high.
101
Sensor 3 Low Warning
Active when the generator is warning due to sensor 3 is too low.
102
Sensor 3 High Shutdown
Active when the generator is shutdown due to sensor 3 is too
high.
103
Sensor 3 Low Shutdown
Active when the generator is shutdown due to sensor 3 is too
low.
104
Rise Speed Pulse
Action time while entering into warming up period (rise speed
pulse output time of timer settings). It is use to control partial
ECU rise to normal speed. Default action time is 0.1s, and
users can define it according to the requirement.
105
Drop Speed Pulse
Action time while entering into stop idle period (drop speed
pulse output time of timer settings). It is use to control partial
ECU rise to idle speed. Default action time is 0.1s, and users
can define it according to the requirement.
106
1# Light Output
It is 1# light output action.
107
2# Light Output
It is 2# light output action.
108
3# Light Output
It is 3# light output action.
109
4# Light Output
It is 4# light output action.
110
Sensor 1 Open Circuit Shutdown
Active when the generator is shutdown due to sensor 1 open
circuit.
111
Sensor 2 Open Circuit Shutdown
Active when the generator is shutdown due to sensor 2 open
circuit.
112
Sensor 3 Open Circuit Shutdown
Active when the generator is shutdown due to sensor 3 open
circuit.
113
Reserved
114
Mains Normal
Action when mains are normal.
115
Mains Abnormal
Action when mains are abnormal.
116
Mains Over Frequency
Action when mains are over frequency.
117
Mains Under Frequency
Action when mains are under frequency.
118
Mains Over Voltage
Action when mains are over voltage.
119
Mains Under Voltage
Action when mains are under voltage.
7.12 OVER CURRENT ACTION
The formula of over current delay value:
T = t / ((IA/IT)-1)
2
T：Overcurrent delay (second)
