ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 31 of 83
5.3 TRIP AND STOP ALARMS
When the controller detects trip and stop signal, it will send signal to turn off #1～#4 lights and then
generator cooling down and stop.
Table 16 – Trip and Stop Alarms
No.
Type
Detection range
Description
1
Over Current
Always active
When controller detects the current is higher than the
maximum limit of preset value, it will send a ―trip and stop‖
signal and the corresponding alarm information will be
displayed on the LCD.
2
Digital Input 1
Trip and Stop
User-defined
When the controller detects digital input port 1 trip alarms, it
will send a ―trip and stop‖ alarm signal and the
corresponding alarm information will be displayed on the
LCD. If the input port name is configured by users as xxx,
then ―xxx trip and stop‖ will be displayed on the LCD.
3
Digital Input 2
Trip and Stop
User-defined
When the controller detects digital input port 2 trip alarms, it
will send a ―trip and stop‖ alarm signal and the
corresponding alarm information will be displayed on the
LCD. If the input port name is configured by users as xxx,
then ―xxx trip and stop‖ will be displayed on the LCD.
4
Digital Input 3
Trip and Stop
User-defined
When the controller detects digital input port 3 trip alarms, it
will send a ―trip and stop‖ alarm signal and the
corresponding alarm information will be displayed on the
LCD. If the input port name is configured by users as xxx,
then ―xxx trip and stop‖ will be displayed on the LCD.
5
Digital Input 4
Trip and Stop
User-defined
When the controller detects digital input port 4 trip alarms, it
will send a ―trip and stop‖ alarm signal and the
corresponding alarm information will be displayed on the
LCD. If the input port name is configured by users as xxx,
then ―xxx trip and stop‖ will be displayed on the LCD.
6
Digital Input 5
Trip and Stop
User-defined
When the controller detects digital input port 5 trip alarms, it
will send a ―trip and stop‖ alarm signal and the
corresponding alarm information will be displayed on the
LCD. If the input port name is configured by users as xxx,
then ―xxx trip and stop‖ will be displayed on the LCD.
NOTE: The trip and stop alarm types of digital input ports are active only when they are configured by users.
