ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 9 of 83
3 SPECIFICATION
Table 3 – Technical Parameters
Items
Contents
Working Voltage
DC8. 0V to 35. 0V, uninterruptible power supply
Overall Consumption
≤3W (Standby mode: ≤2W; Deep Sleep mode: ≤0.2W)
Gen./Mains Voltage Input:
3 Phase 4 Wire
3 Phase 3 Wire
Single Phase 2 Wire
2 Phase 3 Wire
DC
15V AC - 360V AC (ph-N)
30V AC - 620V AC (ph-ph)
15V AC - 360V AC (ph-N)
15V AC - 360V AC (ph-N)
0V DC - 75V DC
Alternator Frequency
50/60Hz
Speed Sensor Voltage
1. 0 V to 24 V (RMS)
Speed Sensor Frequency
Maximum 10,000 Hz
Starter Relay Output
5A DC B+ power supply output
Configurable Relay Output 1
5A DC B+ power supply output
Configurable Relay Output 2
1A DC B+ power supply output
Configurable Relay Output 3
1A DC B+ power supply output
Configurable Relay Output 4
1A DC30V volt free output
Configurable Relay Output 5
1A DC30V volt free output
Configurable Relay Output 6
1A DC30V volt free output
Configurable Relay Output 7
1A DC30V volt free output
Case Dimensions
135 mm x 110 mm x 44 mm
Panel Cutout
116mm x 90mm
AC CT Secondary Current
DC Current Input
Rated: 5A
Hall sensor’s secondary side current: (4~20)mA
Working Conditions
Temperature: (-25~+70)°C Relative Humidity: (20~93)%RH
Storage Conditions
Temperature:(-25~+70)°C
Protection Level
IP65: rubber seal installed between the controller enclosure and panel
fascia.
Insulation Intensity
Apply AC2.2kV voltage between high voltage terminal and low voltage
terminal;
The leakage current is not more than 3mA within 1min.
Weight
0.34kg
