ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 75 of 83
CAN(L)
13
Engine type: VolvoEDC4
10.9 JOHN DEERE
Table 44 - 21Pins Connector
Terminals of controller
21 pins connector
Remark
Aux. output 1
G, J
Aux. output 1 configured as ―Fuel Output‖.
Starter relay output
D
-
CAN communication shielding line.
CAN(H)
V
CAN(L)
U
Engine type: John Deere
10.10 MTU MDEC
Suitable for MTU engines, 2000 series, 4000series
Table 45 - X1 Pin Connector
Terminals of controller
X1 connector
Remark
Aux. output 1
BE1
Aux. output 1 configured as ―Fuel Output‖.
Start relay output
BE9
E
CAN communication shielding line (connect
with one terminal only).
CAN(H)
G
CAN(L)
F
Engine type: MTU-MDEC-303
10.11 MTU ADEC(SMART MODULE)
It is suitable for MTU engine with ADEC (ECU8) and SMART module.
Table 46 - ADEC(X1 Connector)
Terminals of controller
ADEC (X1port)
Remark
Aux. output 1
X1 10
Aux. output 1 configured as ―Fuel Output‖. X1
Terminal 9 Connected to negative of battery
Start relay output
X1 34
X1 Terminal 33 Connected to negative of
battery
Table 47 - ADEC(X4 Connector)
Terminals of controller
SMART (X4 port)
Remark
X4 3
CAN communication shielding line.
CAN(H)
X4 1
CAN(L)
X4 2
Engine type: MTU-ADEC
