10.12 MTU ADEC (SAM MODULE)
It is suitable for MTU engine with ADEC (ECU7) and SAM module.
Table 48 - ADEC(X1 Connector)
Terminals of controller
ADEC (X1port)
Remark
Aux. output 1
X1 43
Aux. output 1 configured as ―Fuel Output‖.
X1 Terminal 28 Connected to negative of
battery.
Starter relay output
X1 37
X1 Terminal 22 Connected to negative of
battery.
Table 49 - SAM(X23 Connector)
Terminals of controller
SAM (X23 port)
Remark
X23 3
CAN communication shielding line.
CAN(H)
X23 2
CAN(L)
X23 1
Engine type: Common J1939
10.13 PERKINS
It is suitable for ADEM3/ ADEM4 engine control module. Engine type is 2306, 2506, 1106, and 2806.
Table 50 - Connector
Terminals of controller
Connector
Remark
Aux. output 1
1,10,15,33,34
Aux. output 1 configured as ―Fuel Output‖.
Starter relay output
-
Connect to starter coil directly.
-
CAN communication shielding line.
CAN(H)
31
CAN(L)
32
Engine type: Perkins
10.14 SCANIA
It is suitable for S6 engine control module. Engine type is DC9, DC12, and DC16.
Table 51 - B1 Connector
Terminals of controller
B1 connector
Remark
Aux. output 1
3
Aux. output 1 configured as ―Fuel Output‖.
Starter relay output
-
Connect to starter coil directly.
-
CAN communication shielding line.
CAN(H)
9
CAN(L)
10
Engine type: Scania
