ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 55 of 83
No.
Items
Content
Remark
9 SGX 10 bar
10 CMB812
11 SGH 10 bar
12 Curtis
13 SGD 10 bar
14 Reserved
15 Reserved
3
Fuel Level
Sensor
0 Not Used
1 Digital close for low fuel level
2 Digital open for low fuel level
3 User defined
4 VDO Ohm range (10-180)
5 VDO Tube type (90-0)
6 US Ohm range (240-33)
7 GM Ohm range (0-90)
8 GM Ohm range Ohm range (0-30)
9 Ford (73-10)
10 NKZR12/24-1-04 Ohm range (100-0)
11 SGD
12 SGH
13 Reserved
14 Reserved
15 Reserved
The range of user-defined
resistor type sensor is
(0-999.9) Ω; by default 11
SGD sensor curve is selected.
User defined sensor curve can
be set via utility software.
