ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 52 of 83
No.
Parameter
Range
Default
Description
8
Sensor Low
Shutdown
Enable
(0~1)
1
0 Disabled 1 Enabled
9
Set Value
(0~1000)kPa
103
10
Delay
(0~3600)s
3
11
Sensor High
Warning
Enable
(0~1)
0
0 Disabled 1 Enabled
12
Set Value
(0~1000)kPa
0
13
Return Value
(0~1000)kPa
0
14
Delay
(0~3600)s
5
15
Sensor Low
Warning
Enable
(0~1)
1
0 Disabled 1 Enabled
16
Set Value
(0~1000) kPa
124
17
Return Value
(0~1000) kPa
138
18
Delay
(0~3600)s
5
19
User-defined
Sensor Curve
1
st
point X
(Resistance)
(0~1000)
15
X-axis and Y-axis of user
defined sensor curves are
all with 8 points,
Unit of X-axis is Ω，
Units of X-axis are as
follows:
Pressure：kPa
Fuel Level：%
Temp.：℃
20
2
nd
point X
(Resistance)
(0~1000)
30
21
3
rd
point X
(Resistance)
(0~1000)
50
22
4
th
point X
(Resistance)
(0~1000)
86
23
5
th
point X
(Resistance)
(0~1000)
100
24
6
th
point X
(Resistance)
(0~1000)
132
25
7
th
point X
(Resistance)
(0~1000)
168
26
8
th
point X
(Resistance)
(0~1000)
200
27
1
st
point Y(Value)
(0~4000)
0
28
2
nd
point Y(Value)
(0~4000)
100
29
3
rd
point Y(Value)
(0~4000)
200
30
4
th
point Y(Value)
(0~4000)
400
31
5
th
point Y(Value)
(0~4000)
500
32
6
th
point Y(Value)
(0~4000)
700
33
7
th
point Y(Value)
(0~4000)
1000
34
8
th
point Y(Value)
(0~4000)
1000
35
User-defined Strings
User-defined
sensor name
Chinese：机油压
力
English：Oil
Pressure
PC software can write 10
Chinese characters and 20
English characters.
