ALC404 LIGHTING TOWER CONTROLLER USER MANUAL
ALC404 Lighting Tower Controller 2018-11-06 Version 1.1 Page 62 of 83
No.
Type
Description
occurs.
20
Common Alarm
Action when genset common warning, common shutdown,
common trips alarm.
21
Common Trip and Stop Alarm
Action when common trips alarms occur.
22
Common Shutdown Alarm
Action when common shutdown alarms occur.
23
Common Warning Alarm
Action when common warning alarms occur.
24
High Temperature Warning
Action when the input port that configured as ―High Temp
Warning Input‖ is active and controller detects temperature high
warning alarms.
25
High Temperature Shutdown
Action when the input port that configured as ―High Temp
Shutdown Input‖ is active and controller detects temperature
high shutdown alarms.
26
Temp. Sensor Open Shutdown
Action when the input port that configured as ―Temp. Open
Circuit Input‖ is active and controller detects temperature
sensor open circuit shutdown alarms.
27
Reserved
28
Digital Input 1 Active
Action when input port 1 is active.
29
Digital Input 2 Active
Action when input port 2 is active
30
Digital Input 3 Active
Action when input port 3 is active
31
Digital Input 4 Active
Action when input port 4 is active
32
Digital Input 5 Active
Action when input port 5 is active
33
Reserved
34
Emergency Stop
Action when emergency stop alarm occurs.
35
Energize to Stop
Action during ETS delay.
36
Failed to Start
Action when failed start alarm occurs.
37
Fuel Pump Control
It is closed when fuel level (associated sensor data) falls bellow
pre-set ―Fuel Pump On‖ limit value; it is open when fuel level
exceeds pre-set ―Fuel Pump Off‖ limit value or surpasses the
maximum output time of fuel pump.
38
Generator Available
Action in period of generator normal running to hi-speed
cooling.
39
Gen. Over Frequency Warning
Action when generator over frequency warning occurs.
40
Gen. Over Frequency
Shutdown
Action when generator over frequency shutdown alarm occurs.
41
Gen. Over Volt Warning
Active when the voltage exceeds the Over Voltage Warning
setting
42
Gen. Over Volt Shutdown
Active when the voltage exceeds the Over Voltage Shutdown
setting
43
Gen. Under Freq. Warning
Active when the frequency falls below the Under Frequency
Warning setting
44
Gen. Under Freq. Shutdown
Active when the frequency falls below the Under Frequency
Shutdown setting
