SMC Networks SMC8126L2 User Manual

Configuring the Switch
3-8
3
IP DSCP Priority Sets IP Differentiated Services Code Point priority, mapping a
DSCP tag to a class-of-service value
3-152
IP Port Prioriey Status Globally enables or disables IP Port Priority 3-153
IP Port Priority Sets TCP/UDP port priority, defining the socket number and
associated class-of-service value
3-153
QoS 3-154
DiffServ 3-154
Class Map Sets Class Maps 3-155
Policy Map Sets Policy Maps 3-158
Service Policy Defines service policy settings for ports 3-161
IGMP Snooping 3-162
IGMP Configuration Enables multicast filtering; configures parameters for multicast
query
3-163
IGMP Filter Configuration Enables IGMP filtering and throttling for the switch, creates filter
profile numbers
3-159
IGMP Immediate Leave Enables the immediate leave function 3-164
Multicast Router
Port Information
Displays the ports that are attached to a neighboring multicast
router for each VLAN ID
3-165
Static Multicast Router Port
Configuration
Assigns ports that are attached to a neighboring multicast router 3-166
IP Multicast Registration
Table
Displays all multicast groups active on this switch, including
multicast IP addresses and VLAN ID
3-167
IGMP Member Port Table Indicates multicast addresses associated with the selected
VLAN
3-168
IGMP Filter Profile
Configuration
Configures IGMP filter profile controlled groups and access
mode
3-169
IGMP Filter/Throttling Port
Configuration
Assigns IGMP filter profiles to port interfaces and sets throttling
settings
3-171
IGMP Filter/Throttling Trunk
Configuration
Assigns IGMP filter profiles to trunk interfaces and sets throttling
settings
3-171
MVR 3-174
Configuration Globally enables MVR, sets the MVR VLAN, adds multicast
stream addresses
3-175
Port Information Displays MVR interface type, MVR operational and activity
status, and immediate leave status
3-176
Trunk Information Displays MVR interface type, MVR operational and activity
status, and immediate leave status
3-176
Group IP Information Displays the ports attached to an MVR multicast stream 3-178
