WAN Setting
5-5
5
Management IP Address – Specifies an IP address for management of the
wireless AP/Router. Valid IP addresses consist of four decimal numbers, 0 to 255,
separated by periods. (Default: 192.168.2.1.)
Subnet Mask – Indicates the local subnet mask. Select the desired mask from the
drop down menu. (Default: 255.255.255.0)
WAN Setting
Specifies the Internet connection parameters. Click on “Network Settings” followed
by “WAN.”
WAN Connection
By default, the access point WAN port is configured with DHCP enabled. After you
have network access to the access point, you can use the web browser interface to
modify the initial IP configuration, if needed. The options are Static IP, DHCP,
PPPoE, 3G, PPTP, L2TP, Bigpond and WiFi. Each option changes the parameters
below it. (Default: DHCP)
Backup WAN
A backup failsafe connection for the WAN port (Dual WAN.) Options are determined
by the WAN Connection selected. Backup WAN and WAN Connection parameters
are identical for each of their eight equivilent modes: Static IP, DHCP, PPPoE, 3G,
PPTP, L2TP, Bigpond and WiFi. (Default: None)
Main WAN Fallback: When the Backup WAN is enabled, Main WAN Fallback can
be enabled to periodically search the primary WAN port for recovery of the lost
connection. If connection is re-established the connection switches back to the
primary WAN connection. (Default: Disabled)
Note: When 3G is selected as the primary WAN Connection, the Backup WAN cannot
be set to 3G also.
