System Configuration
5-20
5
QoS Setting
The QoS setting page is used to configure Quality of Service (QoS) for Traffic
Prioritization and Bandwidth Management. Quality of Service (QoS) provides users
the control over which type of outgoing data traffic is given priority by the router. The
throughput rate of both the upload and download data passed through the wireless
AP/Router can be throttled.
Figure 5-34. QoS Settings (Router mode)
Bandwidth QoS Setting — The maximum upload and download speeds of the
Internet connection on the WAN port. It is recommended that you set these values at
between 85-90% of your true speeds. Most broadband services are rated in
Megabits per second (Mbps). To convert Mbps to Kilobits per second (Kbps),
multiply the value by 1024. The following table lists the most common broadband
service speeds:
• QoS Bandwidth – Enables the QoS bandwidth management and traffic control.
Mbps Kilobits
1 1024
2 2048
3 3072
4 4069
6 6144
8 8192
12 12288
