Sirius 800 www.snellgroup.com Power Supply and Fan Maintenance
Issue 1 Rev 1 Page 27 © 2014 Snell Limited
4.4.2 Sirius 830 Replacement Fan Part Numbers
The following tables show the replacement fan part numbers for each of the Sirius 830 frame
configuration options. To identify which configuration your frame is see Table 4.
Sirius 830 Replacement Front Fans
Sirius 830 Replacement Rear Fans
Sirius 830 Front View
Mark 1 Frame
Configuration
Mark 2 Frame
Configuration
Mark 3 Frame
Configuration
Fan Spare Part Numbers
Crosspoint and Multiviewer Door
8 x FGAEY
1270C
8 x FGAEY
1270C
8 x FGAEY
6081270
Input/Output Module Door
8 x FGAEY
1270C
8 x FGAEY
6080890 Y
8 x FGAEY
6081280
Table 5. Sirius 830 Front Fan Part Numbers
Sirius 830 Rear View
Mark 1 Frame
Configuration
Mark 2 Frame
Configuration
Mark 3 Frame
Configuration
Fan Spare Part Numbers
Rear Crosspoint Fans
4 x FGAEY
1270C
4 x FGAEY
6080890 Y
4 x FGAEY
6081280
Table 6. Sirius 830 Rear Fan Part Numbers
