1. About this Manual
This Maintenance & Upgrade manual describes how to maintain and upgrade the Sirius 830,
840 and 850 routers. Refer to the appropriate Installation Manuals for details on how to
unpack, install and test the Sirius 800 routers and the Sirius 800 User manual for operational
details.
Refer to the Workbench Manual for details on configuring hardware and software panels. If
you have any questions regarding the installation and setup of your product, please refer to
the table in Section 1.2 for Customer Service contact details.
1.1 Software and Firmware Release Details
This version of the Sirius 800 maintenance & upgrade manual documents the features and
functions available with Workbench version 3.15.x and firmware release PA1250x. These
features are shown in summary in Table 1.
Firmware release notes are included with the firmware and are available on request from
Snell Customer Service, see section 1.2 for contact details.
1.1.1 Export System Information (Nucleus2 2463)
Router system information can be exported to a CSV file by right clicking on the controller in
the configuration screen of Workbench. System information saved includes; hardware module
types, hardware versions, firmware versions, software versions, Workbench details and
database location information. See the Workbench manual for information on using
Workbench.
Firmware
Release
Version
Module Features Supported
3.0.x 2463
AHP control
(software/firmware supplied with the Workbench release).
PA1250x 4915
Gain, Phase Invert, Left/Right Swap, Left Both, Right Both,
Mono Mix.
PA1250x 5919
Audio De-embedding, Audio Delay, Gain, Phase Invert, 16
Channel Mix and Channel Swap (Shuffle), Video Frame/Line
Sync, Video Delay.
PA1250x 4929
Gain, Phase Invert, Left/Right Swap, Left Both, Right Both,
Mono Mix, Audio Delay, Sample Rate Convert.
PA1250x 5949
16 Channel Mix, Channel Swap (Shuffle), Gain, Phase Invert,
Audio Delay and Audio Embedding, Video Frame/Line Sync,
Video Delay.
Crosspoint Modules Crosspoint Modules
PA1250x 5903. Audio crosspoint operation.
PA1250x 5905 Video crosspoint operation.
Modules no longer supplied with new systems
PA1250x 5915
Audio De-embedding, Gain, Phase Invert, 16 Channel Mix and
Channel Swap (Shuffle).
PA1250x 4925
Gain, Phase Invert, Left/Right Swap, Left Both, Right Both,
Mono Mix.
PA1250x 5925
16 Channel Mix, Channel Swap (Shuffle), Gain, Phase Invert
and Audio Embedding.
Table 1. Firmware Release History
